UCLP200

Unit NO.Dimensions ( mm / in. )Bolt Size mm/in.Bearing No.Housing No.Weight (kg)
dhaebs1s2gwtB1
UKP205;H2305 20 36.5 140 105 38 13 19 15 71 48 35 M10 UK205;H2305 P205 0.81
UKP205;HE2305 3/4 1-7/16 5-1/2 4-1/8 1-1/2 1/2 3/4 19/32 2-25/32 1-57/64 1.378 3/8 UK205;HE2305 P205 0.81
UKP206;H2306 25 42.9 160 121 44 17 20 17 84 53 38 M14 UK206;H2306 P206 1.26
UKP206;HS2306 7/8 1-11/16 6-19/64 4-3/4 1-47/64 43/64 25/32 43/64 3-5/16 2-5/64 1.496 1/2 UK206;HS2306 P206 1.26
UKP206;HE2306 1 1-11/16 6-19/64 4-3/4 1-47/64 43/64 25/32 43/64 3-5/16 2-5/64 1.496 1/2 UK206;HE2306 P206 1.26
UKP207;H2307 30 47.6 167 127 48 17 20 18 93 59.5 43 M14 UK207;H2307 P207 1.53
UKP207;HS2307 1-1/8 1-7/8 6-9/16 5 1-7/8 43/64 25/32 45/64 3-21/32 2-11/32 1.693 1/2 UK207;HS2307 P207 1.53
UKP208;H2308 35 49.2 184 137 54 17 20 18 100 69 46 M14 UK208;H2308 P208 1.93
UKP208;HE2308 1-1/4 1-15/16 7-1/4 5-13/32 2-1/8 43/64 25/32 45/64 3-15/16 2-23/32 1.811 1/2 UK208;HE2308 P208 1.93
UKP208;HS2308 1-3/8 1-15/16 7-1/4 5-13/32 2-1/8 43/64 25/32 45/64 3-15/16 2-23/32 1.811 1/2 UK208;HS2308 P208 1.93
UKP209;H2309 40 54 190 146 54 17 20 20 106 69 50 M14 UK209;H2309 P209 2.18
UKP209;HA2309 1-7/16 2-1/8 7-15/32 5-3/4 2-1/8 43/64 25/32 25/32 4-11/64 2-23/32 1.969 1/2 UK209;HA2309 P209 2.18
UKP209;HE2309 1-1/2 2-1/8 7-15/32 5-3/4 2-1/8 43/64 25/32 25/32 4-11/64 2-23/32 1.969 1/2 UK209;HE2309 P209 2.18
UKP209;HS2309 1-5/8 2-1/8 7-15/32 5-3/4 2-1/8 43/64 25/32 25/32 4-11/64 2-23/32 1.969 1/2 UK209;HS2309 P209 2.18
UKP210;H2310 45 57.2 206 159 60 20 23 21 113 74.5 55 M16 UK210;H2310 P210 2.78
UKP210;HS2310 1-5/8 2-1/4 8-1/8 6-1/4 2-3/8 25/32 29/32 53/64 4-29/64 2-15/16 2.165 5/8 UK210;HS2310 P210 2.78
UKP210;HA2310 1-11/16 2-1/4 8-1/8 6-1/4 2-3/8 25/32 29/32 53/64 4-29/64 2-15/16 2.165 5/8 UK210;HA2310 P210 2.78
UKP210;HE2310 1-3/4 2-1/4 8-1/8 6-1/4 2-3/8 25/32 29/32 53/64 4-29/64 2-15/16 2.165 5/8 UK210;HE2310 P210 2.78
UKP211;H2311 50 63.5 219 171 60 20 23 23 125 76 59 M16 UK211;H2311 P211 3.39
UKP211;HS2311 1-7/8 2-1/2 8-5/8 6-47/64 2-3/8 25/32 29/32 29/32 4-59/64 3 2.323 5/8 UK211;HS2311 P211 3.39
UKP211;HA2311 1-15/16 2-1/2 8-5/8 6-47/64 2-3/8 25/32 29/32 29/32 4-59/64 3 2.323 5/8 UK211;HA2311 P211 3.39
UKP211;HE2311 2 2-1/2 8-5/8 6-47/64 2-3/8 25/32 29/32 29/32 4-59/64 3 2.323 5/8 UK211;HE2311 P211 3.39
UKP212;H2312 55 69.8 241 184 70 20 23 25 138 89 62 M16 UK212;H2312 P212 4.52
UKP212;HS2312 2-1/8 2-3/4 9-1/2 7-1/4 2-3/4 25/32 29/32 63/64 5-7/16 3-1/2 2.441 5/8 UK212;HS2312 P212 4.52
UKP213;H2313 60 76.2 265 203 70 25 28 27 150 89 65 M20 UK213;H2313 P213 5.47
UKP213;HA2313 2-3/16 3 10-7/16 8 2-3/4 63/64 1-3/32 1-1/16 5-29/32 3-1/2 2.559 3/4 UK213;HA2313 P213 5.47
UKP213;HE2313 2-1/4 3 10-7/16 8 2-3/4 63/64 1-3/32 1-1/16 5-29/32 3-1/2 2.559 3/4 UK213;HE2313 P213 5.47
UKP213;HS2313 2-3/8 3 10-7/16 8 2-3/4 63/64 1-3/32 1-1/16 5-29/32 3-1/2 2.559 3/4 UK213;HS2313 P213 5.47
UKP215;H2315 65 82.6 275 217 74 25 28 28 162 99 73 M20 UK215;H2315 P215 6.84
UKP215;HA2315 2-7/16 3-1/4 10-53/64 8-35/64 2-29/32 63/64 1-3/32 1-3/32 6-3/8 3-57/64 2.874 3/4 UK215;HA2315 P215 6.84
UKP215;HE2315 2-1/2 3-1/4 10-53/64 8-35/64 2-29/32 63/64 1-3/32 1-3/32 6-3/8 3-57/64 2.874 3/4 UK215;HE2315 P215 6.84
UKP216;H2316 70 88.9 292 232 78 25 28 30 174 109 78 M20 UK216;H2316 P216 8.29
UKP216;HA2316 2-11/16 3-1/2 11-1/2 9-1/8 3-1/16 63/64 1-3/32 1-3/16 6-27/32 4-19/64 3.071 3/4 UK216;HA2316 P216 8.29
UKP216;HE2316 2-3/4 3-1/2 11-1/2 9-1/8 3-1/16 63/64 1-3/32 1-3/16 6-27/32 4-19/64 3.071 3/4 UK216;HE2316 P216 8.29
UKP217;H2317 75 95.2 310 247 83 25 28 32 185 113.2 82 M20 UK217;H2317 P217 9.97
UKP217;HA2317 2-15/16 3-3/4 12-13/64 9-23/32 3-17/64 63/64 1-3/32 1-1/4 7-9/32 4-29/64 3.228 3/4 UK217;HA2317 P217 9.97
UKP217;HE2317 3 3-3/4 12-13/64 9-23/32 3-17/64 63/64 1-3/32 1-1/4 7-9/32 4-29/64 3.228 3/4 UK217;HE2317 P217 9.97
UKP218;H2318 80 101.6 327 262 88 27 30 33 198 123 86 M22 UK218;H2318 P218 11.89
UKP218;HA2318 3-3/16 4 12-7/8 10-5/16 3-15/32 1-1/16 1-3/16 1-19/64 7-51/64 4-27/32 3.386 7/8 UK218;HA2318 P218 11.89
